EMATs for Pipeline Inspection

In the field of non-destructive testing (NDT), pipeline inspection is crucial for maintaining the integrity and safety of pipelines in various industries. Electromagnetic acoustic transducers (EMATs) have emerged as a powerful tool for comprehensive pipeline assessments, offering advantages over traditional inspection methods. Sonemat provides advanced EMAT solutions for pipeline inspection, including thickness gauging, corrosion and erosion monitoring, defect detection, and weld inspection.

Introduction: The Role of EMATs in Pipeline Inspection

At Sonemat, we leverage the capabilities of EMAT technology to deliver superior pipeline inspection solutions. Unlike traditional piezoelectric transducers, EMATs generate ultrasonic waves without direct contact with the material, making them ideal for inspecting pipelines in challenging environments. Our range of EMAT probes and electronics is designed to meet the specific needs of pipeline inspections, ensuring accurate and reliable results.

Key Applications of EMATs in Pipeline Inspection

1. Thickness Gauging

Accurate thickness gauging is essential for assessing the condition of pipelines and ensuring their structural integrity. EMATs provide precise measurements without the need for couplants, making them suitable for pipelines with rough or coated surfaces.

• Advantages:
  • Non-contact measurement
  • Effective on various materials
  • High precision and reliability

2. Corrosion and Erosion Monitoring

Monitoring corrosion and erosion is critical for preventing pipeline failures. EMATs can detect and map areas of corrosion and erosion, providing valuable data for maintenance planning and risk assessment.

• Benefits:
  • Early detection of corrosion and erosion
  • Detailed mapping capabilities
  • Real-time monitoring

3. Defect Detection

Detecting defects such as cracks and inclusions is vital for pipeline safety. EMATs offer high sensitivity to various types of defects, ensuring comprehensive pipeline assessments.

• Key Features:
  • High sensitivity to cracks and inclusions
  • Capable of detecting both surface and subsurface defects
  • Reliable performance in harsh environments

4. Weld Inspection

Welds are critical points in pipelines that require thorough inspection. EMATs provide detailed weld inspections, identifying defects that could compromise the integrity of the pipeline.

• Applications:
  • Inspection of weld quality
  • Detection of weld defects
  • Ensuring compliance with safety standards

Types of EMATs for Pipeline Inspection

Sonemat offers two main types of EMATs for pipeline inspection: bulk-wave EMATs and guided-wave EMATs. Each type has its specific applications and advantages.

1. Bulk-Wave EMATs

Bulk-wave EMATs are used for thickness gauging, defect detection, and general material characterization. They generate ultrasonic waves that propagate through the bulk of the material, providing detailed information about its internal structure.

• Key Products:
  • Shear Wave EMATs: Ideal for thickness gauging and defect detection.
  • Longitudinal Wave EMATs: Suitable for general material characterization and flaw detection.

2. Guided-Wave EMATs

Guided-wave EMATs are used for long-range inspection of pipelines. They generate waves that travel along the length of the pipeline, making them ideal for detecting corrosion, erosion, and defects over extended distances.

• Key Products:
  • SH Wave EMATs: Excellent for detecting localized defects and corrosion.
  • Lamb Wave EMATs: Suitable for long-range corrosion and erosion monitoring.

Sonemat’s EMAT Solutions for Pipeline Inspection

EMAT Adapter GS2020

The EMAT Adapter GS2020 allows operators to use conventional UT thickness gauges and flaw detectors with EMAT technology. This adapter is perfect for those new to EMATs, providing sensitive amplification and averaging for excellent signals.

• Features:
  • Compatible with conventional UT equipment
  • Cost-effective for beginners
  • High sensitivity and signal processing

Toneburst Pulser-Receiver TBPR-1000

Our Toneburst Pulser-Receiver TBPR-1000 is a versatile guided-wave product designed to work with our range of guided-wave EMATs (SH EMATs, Lamb, Rayleigh) across a frequency range of 20kHz to 1MHz. This battery-powered device can be controlled via dials or a computer, offering a semi-automated setup with Sonemat’s software. It also features built-in analogue to digital conversion (ADC) for precise data acquisition.

• Benefits:
  • Supports a wide frequency range (20kHz to 1MHz)
  • Battery-powered for field portability
  • Dual control options: manual dials or computer interface
  • Semi-automated setup with Sonemat’s software
  • Built-in ADC for accurate data conversion

Why Choose Sonemat for Pipeline Inspection?

Choosing Sonemat for your pipeline inspection needs means partnering with a team dedicated to innovation, quality, and customer satisfaction. Here’s why you should choose us:

• Expertise: Nearly 20 years of experience in NDT and EMAT technology.
• Custom Solutions: Tailored products designed to meet specific pipeline inspection requirements.
• Comprehensive Support: From initial consultation to ongoing maintenance, we offer full support throughout your project.

Case Studies: Success Stories

Case Study 1: Corrosion Monitoring in Oil and Gas Pipelines

A client in the oil and gas industry needed reliable corrosion monitoring for their pipelines. We provided custom EMAT solutions that allowed early detection and detailed mapping of corrosion, helping the client maintain the integrity and safety of their infrastructure.

Case Study 2: Weld Inspection for New Pipeline Installations

For a major pipeline installation project, we delivered advanced EMAT solutions for weld inspection. Our EMATs detected potential defects in the welds, ensuring the quality and safety of the new pipeline before it was put into operation.

Case Study 3: Long-Range Pipeline Inspection in Chemical Processing Plant

We deployed our guided-wave EMATs for a comprehensive inspection of pipelines in a chemical processing plant. The long-range inspection capabilities allowed us to detect corrosion and erosion over extended distances, providing valuable data for maintenance planning.

Conclusion: Partner with Sonemat for Advanced EMAT Solutions

If you’re looking to enhance your pipeline inspection capabilities, Sonemat offers the expertise and advanced solutions you need. Our range of custom EMAT products and comprehensive support ensures you receive precise and reliable measurements for your applications. Contact us today to learn more about our products and how we can assist you in achieving superior results.

FAQs

What types of pipelines can your EMATs inspect?

Our EMATs can inspect a wide range of pipelines, including those in oil and gas, chemical processing, and power generation industries.

How do EMATs perform in high-temperature environments?

Our water-cooled EMATs can operate at temperatures up to 1000°C, while other high-temperature EMATs are designed for reliable performance up to 200°C and 550°C without cooling.

Can your EMATs be customized for specific pipeline inspection needs?

Yes, we offer custom solutions to meet the unique requirements of your pipeline inspections. Contact us to discuss your specific needs.
